External Thread Grinding Machines

Matrix 0550

  • Max Diameter Admitted 150 mm
  • Max Diameter Ground 100 mm
  • Min Diameter Ground 5 mm
  • Max Length Between Centers 500 mm
  • Max Length of Thread Ground Between Centers 400 mm (component Dependent)
  • Lead Range 300 mm

Matrix 0850

  • Max Diameter Admitted 350 mm
  • Max Diameter Ground 350 mm
  • Min Diameter Ground 10 mm
  • Max Length Between Centers 800 mm
  • Max Length of Thread Ground Between Centers 800 mm (component Dependent)
  • Lead Range 300 mm

Matrix 2250

  • Max Diameter Admitted 350 mm
  • Max Diameter Ground 35 0mm
  • Min Diameter Ground 10 mm
  • Max Length Between Centers 2250 mm
  • Max Length of Thread Ground Between Centers 2200 mm
  • Lead Range 300 mm

Internal Thread Grinding Machines

Matrix 0860

  • Max Diameter Swing 160 mm
  • Max Diameter Ground Bore 80 mm
  • Min Diameter Ground Bore 20 mm
  • Length of Ground Bore 20~60 mm

Matrix 3060

  • Max Diameter Swing 160 mm
  • Max Diameter Ground Bore 80 mm
  • Min Diameter Ground Bore 20 mm
  • Length of Ground Bore 20~60 mm

Matrix 5060

  • Max Diameter Swing 500 mm
  • Max Diameter Ground Bore 400 mm
  • Min Diameter Ground Bore 16 mm
  • Max Length of Ground Bore 250 mm
